Specifications |
|
|
TX40 |
|
Capacity |
|
|
| §
Swing over bed cover |
mm |
400 |
| §
Maximum turning diameter |
mm |
250 |
| §
Standard turning diameter |
mm |
225 |
| §
Distance between centers |
mm |
450 |
| §
Maximum turning length |
mm |
400 |
| §
Maximum bar capacity |
mm |
51 |
|
|
|
|
Main spindle |
|
|
| §
Spindle nose |
mm |
A2-6 |
| §
Spindle bore |
mm |
63 |
| §
Chuck size |
mm |
200 |
| §
Speed range |
mm |
50-3500 |
| §
Spindle bearing inner dia |
mm |
100(110) |
§
Spindle motor power
30 min. Rating |
kw |
7/5.5 |
|
|
|
|
Slides |
|
|
| §
Cross (x-axis) travel |
mm |
180 |
| §
Longitudinal (x-axis) travel |
mm |
450 |
| §
Rapid feed X-axis |
m/min |
20 |
|
Z-axis |
m/min |
20 |
|
|
|
|
Turret |
|
|
| §
Nos. of (stations) |
|
8 |
| §
Boring bar capacity |
mm |
40 |
| §
Tool cross section |
mm |
25x25 |
|
|
|
|
Tail stock |
|
|
| §
Quill diameter |
mm |
80 |
| §
Quill stroke |
mm |
100 |
| §
Quill actuation |
|
Hydraulic |
| §
Tail stock |
mm |
300 |
|
|
|
|
ACCURACY
|
|
|
| §
Positioning |
|
+/- 0.010 |
| §
Repeatability |
|
+/- 0.005 |
|
|
|
|
DIMENSIONS ( L X B
X H ) |
mm |
2100x1500x1600 |
|
WEIGHT |
kgs |
3150 |
|
|
|
| CNC CONTROLLER |
|
SEIMENS 802 D |
|
|
|
|
Standard FEATURES |
|
§ SIEMENS / FANUC CNC System |
|
§ AC Servo Motor & Drive for Spindle |
|
§ AC Servo Motors & Digital drives for
both X & Z Axis |
|
§ Spindle Nose A2-6 having front bearing inner dia.
100-mm |
|
§ Spindle Speed Range 50-4000 RPM |
|
§ Spindle Power 7 KW ( 30- minutes rating ) / 5.5 KW
Continuous rating. |
|
§ Precision Class C3
ground Ball Screws with Double Nuts for X & Z Axes. |
|
§ Linear Motion Guide
ways Class H for both X & Z Axis. |
|
§ Rapid traverse rate 20-meters/min for X & Z Axis. |
|
§ Tail stock with hydraulic quill and with build-in live
center. |
|
§ Bi-direction electromechanically 8-Station random access
Tool Turret |
|
§ Hydraulic power pack |
|
§ Panel AC |
§ Dia. 200-mm3-Jaw
Open Center Power Chuck with Hard & Soft Jaws set and with
Hydraulic
Hollow Center High Speed Rotary Cylinder to accommodate 51-mm dia. bar |
|
§ Manual Pulse
Generator |
|
§ CNC Fearture as per
SIEMENS / FANUC standard |
|
§ Set of services
tools |
|
§ Power Input : AC 3
Phase 415 V +_ 6%, 50 Hz +_1 Hz, 12 KVA |
|
RECOMMENDED Accessories |
|
§ Chip Conveyor |
|
§ Servo Voltage
Stabilizer - 15 KVA/3Ph |
|
|
